Fuel Tank for Forklift

Fuel Tank for Forklift - Some fuel tanks are made by expert metal craftsmen, although nearly all tanks are manufactured. Restoration and custom tanks could be found on aircraft, automotive, tractors and motorcycles.

When constructing fuel tanks, there are a series of requirements that must be followed. Firstly, the tanks craftsman will make a mockup to be able to find out the dimensions of the tank. This is normally done using foam board. Next, design concerns are dealt with, consisting of where the seams, drain, outlet, baffles and fluid level indicator will go. The craftsman must find out the alloy, temper and thickness of the metallic sheet he will use so as to construct the tank. As soon as the metal sheet is cut into the shapes required, many pieces are bent so as to create the basic shell and or the ends and baffles for the fuel tank.

In racecars and aircraft, the baffles contain "lightening" holes, which are flanged holes which provide strength to the baffles, while also reducing the tank's weight. Openings are added toward the ends of construction for the fuel pickup, the filler neck, the fluid-level sending unit and the drain. Occasionally these holes are added as soon as the fabrication process is done, other times they are created on the flat shell.

After that, the ends and baffles can be riveted into place. The rivet heads are normally brazed or soldered so as to stop tank leaks. Ends could next be hemmed in and flanged and sealed, or brazed, or soldered making use of an epoxy kind of sealant, or the ends could likewise be flanged and then welded. After the soldering, brazing and welding has been done, the fuel tank is tested for leaks.

Click to Download the pdf
